Nickel Perforated Metal

Go Back

Nickel Perforated Metal

Nickel perforated mesh is made of nickel sheet.The hole size can be big hole or small hole.The

width and length can as use design and make the same size.Surface need polished treatment.

Makre sure surface smooth,clean and bright.

Nickel perforated mesh specification list:

Online Message

More Details

Nickel perforated mesh description:
Nickel perforated mesh is made of nickel sheet.The hole size can be big hole or small hole.The
width and length can as use design and make the same size.Surface need polished treatment.
Makre sure surface smooth,clean and bright.
Nickel perforated mesh specification list:
Material
Pure nickel wire N2 N4/Ni201 N6/Ni200 N8 Ni205 Ni270
Thickness
0.1mm-2mm or as your required
Hole size
2.5mm,3mm,3.5mm,4mm etc
Hole shape
Round,square and so on
Surface
smooth,clean,bright
Export market
USA,UK,France,New zealand,Aurtralia,UAE,South africa etc
MOQ
1 SQM
Nickel perforated mesh feature:
good quality material
standard specification
uniform hole size
surface smooth and beautiful
acid resistance,
alkali resistance,
temperature resistance
easy use
Nickel perforated mesh packing way:
Wrapped with plastic film
wrapped with waterproof paper
wrapped with air bubble film
load in carton
load in pallet
load in wooden box
Nickel perforated mesh application:
used in battery,
chemical,
mining,
telecommunications,
hydrogen production industry and scientific research departments to filter machine
Good advantages:
1.pure quality material
2. standard sheet thickness,
3. Standard hole size
4. standrad width and length
5. uniform hole size
6. appearance beautiful and smooth
7. surface bright and clean
8. easy install and ship
9. use long time
10. save cost
Normal Packages way for export:
1) waterproof cloth
2) woven bag
3) plastic film
4) In pallet
5) In wooden box
6) as your required
Normally Type As Following
Nickel Perforated Metal
Pattern
Hole Size
Pitch
% Open Area
Sheet Size
Thickness
1
1.00 mm
2.00 mm
23
2 m x 1 m
1.00 mm
2
1.50 mm
3.00 mm
23
2 m x 1 m
1.00 mm
3
1.50 mm
3.00 mm
23
2 m x 1 m
1.50 mm
4
2.00 mm
3.00 mm
40
2 m x 1 m
1.00 mm
5
2.00 mm
3.50 mm
30
2 m x 1 m
1.50 mm
6
2.50 mm
4.00 mm
35
2 m x 1 m
1.00 mm
7
2.50 mm
4.00 mm
35
2 m x 1 m
1.50 mm
8
3.00 mm
5.00 mm
33
2 m x 1 m
1.00 mm
9
3.00 mm
5.00 mm
33
2 m x 1 m
1.50 mm
10
3.00 mm
5.00 mm
33
2 m x 1 m
2.00 mm
11
3.00 mm
5.00 mm
33
2 m x 1 m
3.00 mm
12
3.00 mm
4.00 mm
50
2 m x 1 m
2.00 mm
13
3.00 mm
5.00 mm
36
2 m x 1 m
1.00 mm
14
4.00 mm
6.00 mm
40
2 m x 1 m
1.50 mm
15
4.00 mm
6.00 mm
40
2 m x 1 m
3.00 mm
16
4.50 mm
15.00 mm
7
2 m x 1 m
1.50 mm
17
5.00 mm
8.00 mm
35
2 m x 1 m
1.00 mm
18
5.00 mm
8.00 mm
35
2 m x 1 m
1.50 mm
19
5.00 mm
8.00 mm
35
2 m x 1 m
3.00 mm
20
5.00 mm
8.00 mm
39
2 m x 1 m
1.00 mm
21
6.00 mm
9.00 mm
40
2 m x 1 m
1.00 mm
22
6.00 mm
9.00 mm
40
2 m x 1 m
1.50 mm
23
6.00 mm
9.00 mm
40
2 m x 1 m
3.00 mm
24
6.00 mm
10.00 mm
33
2 m x 1 m
6.00 mm
25
8.00 mm
11.00 mm
48
2 m x 1 m
1.00 mm
26
8.00 mm
12.00 mm
40
2 m x 1 m
1.50 mm
27
8.00 mm
11.00 mm
48
2 m x 1 m
2.00 mm
28
10.00 mm
15.00 mm
40
2 m x 1 m
1.00 mm
29
10.00 mm
15.00 mm
40
2 m x 1 m
1.50 mm
30
10.00 mm
15.00 mm
40
2 m x 1 m
3.00 mm
31
10.00 mm
15.00 mm
40
2 m x 1 m
5.00 mm
32
10.00 mm
14.00 mm
51
2 m x 1 m
1.50 mm
33
12.00 mm
16.00 mm
51
2 m x 1 m
3.00 mm
34
15.00 mm
20.00 mm
54
2 m x 1 m
2.00 mm
35
15.00 mm
21.00 mm
46
2 m x 1 m
2.00 mm
36
20.00 mm
28.00 mm
46
2 m x 1 m
3.00 mm

Nickel Perforated Metal

Precision Filtration Solutions for a Cleaner, Efficient Industry

Custom-designed, Filtration solutions

.

Versatile and Precise Filtering

A perfect union of craftsmanship and innovation, we customize wire mesh filters to meet your exact need

FILTERE SCREEN EXPERT DESIGN

STD woven mesh can meet ASTM, AS, BS, DIN, EN, GOST standard . We can design non-standard wire mesh according to the sketches and drawings. With advanced technology and extensive industry expertise, STD ensures high-quality production and consistently meets the diverse needs of global clients.

Material	Pure nickel wire N2 N4/Ni201 N6/Ni200 N8 Ni205 Ni270
Thickness	0.1mm-2mm or as your required
Hole size	2.5mm,3mm,3.5mm,4mm etc
Hole shape	Round,square and so on
Surface	smooth,clean,bright
Export market	USA,UK,France,New zealand,Aurtralia,UAE,South africa etc
MOQ	1 SQM

Nickel Perforated Metal
Pattern	Hole Size	Pitch	% Open Area	Sheet Size	Thickness
1	1.00 mm	2.00 mm	23	2 m x 1 m	1.00 mm
2	1.50 mm	3.00 mm	23	2 m x 1 m	1.00 mm
3	1.50 mm	3.00 mm	23	2 m x 1 m	1.50 mm
4	2.00 mm	3.00 mm	40	2 m x 1 m	1.00 mm
5	2.00 mm	3.50 mm	30	2 m x 1 m	1.50 mm
6	2.50 mm	4.00 mm	35	2 m x 1 m	1.00 mm
7	2.50 mm	4.00 mm	35	2 m x 1 m	1.50 mm
8	3.00 mm	5.00 mm	33	2 m x 1 m	1.00 mm
9	3.00 mm	5.00 mm	33	2 m x 1 m	1.50 mm
10	3.00 mm	5.00 mm	33	2 m x 1 m	2.00 mm
11	3.00 mm	5.00 mm	33	2 m x 1 m	3.00 mm
12	3.00 mm	4.00 mm	50	2 m x 1 m	2.00 mm
13	3.00 mm	5.00 mm	36	2 m x 1 m	1.00 mm
14	4.00 mm	6.00 mm	40	2 m x 1 m	1.50 mm
15	4.00 mm	6.00 mm	40	2 m x 1 m	3.00 mm
16	4.50 mm	15.00 mm	7	2 m x 1 m	1.50 mm
17	5.00 mm	8.00 mm	35	2 m x 1 m	1.00 mm
18	5.00 mm	8.00 mm	35	2 m x 1 m	1.50 mm
19	5.00 mm	8.00 mm	35	2 m x 1 m	3.00 mm
20	5.00 mm	8.00 mm	39	2 m x 1 m	1.00 mm
21	6.00 mm	9.00 mm	40	2 m x 1 m	1.00 mm
22	6.00 mm	9.00 mm	40	2 m x 1 m	1.50 mm
23	6.00 mm	9.00 mm	40	2 m x 1 m	3.00 mm
24	6.00 mm	10.00 mm	33	2 m x 1 m	6.00 mm
25	8.00 mm	11.00 mm	48	2 m x 1 m	1.00 mm
26	8.00 mm	12.00 mm	40	2 m x 1 m	1.50 mm
27	8.00 mm	11.00 mm	48	2 m x 1 m	2.00 mm
28	10.00 mm	15.00 mm	40	2 m x 1 m	1.00 mm
29	10.00 mm	15.00 mm	40	2 m x 1 m	1.50 mm
30	10.00 mm	15.00 mm	40	2 m x 1 m	3.00 mm
31	10.00 mm	15.00 mm	40	2 m x 1 m	5.00 mm
32	10.00 mm	14.00 mm	51	2 m x 1 m	1.50 mm
33	12.00 mm	16.00 mm	51	2 m x 1 m	3.00 mm
34	15.00 mm	20.00 mm	54	2 m x 1 m	2.00 mm
35	15.00 mm	21.00 mm	46	2 m x 1 m	2.00 mm
36	20.00 mm	28.00 mm	46	2 m x 1 m	3.00 mm
