Dutch weave woven wire mesh is manufactured from stainless steel wire. Different from plain weave woven wire mesh and twill woven wire mesh, the dutch weave woven wire mesh has different diameter in the weft and warp directions. Commonly the warp wire is coarser wire, which can supply the high tensile strength for the wire mesh. The weft wire is finer wire, which can ensure the excellent filtering performance. This unique structure with greater strength and finer openings is primarily used as a filter cloth.

Type of dutch weave woven wire mesh

Dutch weave woven wire mesh can be woven in both plain dutch weave and twill dutch weave. They have their own characteristics, which can be used in different applications. There is also a specially designed and applied products - reverse dutch woven wire mesh in another page, which the warp wire lies close together and has thinner wire diameter than the warp wire.

Plain dutch weave woven wire cloth

Plain dutch weave woven wire cloth.

Plain dutch weave is the combination of dutch weave and plain weave. It has two sizes of wire diameters like the dutch weave. Each warp wire with coarse wire diameter passes alternately over and under one weft wire to supply high tensile strength for the netting. The weft wire with fine wire diameter alternately passes over and under one warp wire to form a fine opening for filtering.

The plain dutch weave woven wire cloth is mainly used for filtering and separating liquid and slurry products.

Advantages than the plain weave woven wire mesh

• Greater mechanical stability.
• Finer opening for better filtration efficiency and quality.
• Coarser wire for higher tensile strength.
•

• Twill dutch weave woven wire mesh


  Twill dutch weave woven wire cloth.

  Twill dutch woven wire mesh is the combination of dutch weave and twill weave. The weft wires passes alternately over and under two warp wire forming a finer mesh in the warp direction and the warp wires forms a coarser mesh in the warp direction in the same weaving.

  Twill dutch woven wire mesh is superior to the twill woven wire cloth because of the finer openings. It can support greater loads than the dutch weave woven wire mesh. It is used for filtering heavy materials.

  Advantages than the twill weave woven wire mesh

• Better filtering performance.
• Higher tensile strength.
• Can be used for filtering ultra-fine products.
• Much more stable structure.
•

• Applications of dutch weave woven wire mesh

• Dutch weave woven wire mesh is mainly used for filtering. It provides superior filtration capabilities for a wide range of areas applications.
  • Aerospace.
  • Petrochemical.
  • Pharmaceutical.
  • Mining.
  • Waste water.
• According to the material of filtering, the plain dutch and twill dutch can be used in different applications.
  • The plain dutch weave woven wire mesh is mainly used for filtering and separating liquid and slurry products.
  • The twill dutch weave woven wire mesh is used for filtering heavy materials.

• Package of dutch weave woven wire mesh

• Waterproof brown paper.
• Wooden box.
•
